Base Machine
TypeEurocomach ES60
EngineKubota V2607
Engine Power46HP - 34kW
Fuel Tank70 lt
Hydraulic Tank65 lt
Drilling Performance
Diameter800 mm
Max Depth16 m
Crowd System
Pull Down Force8000 kgm
Extraction Force15000 kgm
Rotary Stroke700 mm
Rotary Head
Nominal Torque2500 kgm
Drilling Speed24 RPM
Spin off Speed60 RPM
Transport
Width1960 mm
Lenght3715 mm
Height2447 mm
Weight approx9000 kg
Mast
Inclination Angle dx/sx3 deg
Mast Vertical Stroke1200 mm
Winches
Main Winch line pull3500 kgm
Aux Winch line pull1000 kgm
Hydraulic System
Main Pumps140 lt/min
Secondary Pumps17 lt/min
Working Pressure260 bar
Kelly Bar OptionsØ 355 mm
Kelly Bar Elements Lenght Depth Option 1 6 2800 mm 16 m Other kelly bars available on request
Base Machine
Enginemany options
Engine Power80HP - 60kW
Fuel Tank90 lt
Hydraulic Tank350 lt
Drilling Performance
Diameter800 mm
Max Depth18 m
Crowd System
Pull Down Force8000 kgm
Extraction Force15000 kgm
Rotary Stroke1000 mm
Rotary Head
Nominal Torque3500 kgm
Drilling Speed24 RPM
Spin off Speed60 RPM
Transport
Width1350 mm
Lenght4350 mm
Height2635 mm
Weight approx7000 kg
Mast
Inclination Angle dx/sx3 deg
Mast Vertical Stroke1200 mm
Winches
Main Winch line pull4500 kgm
Aux Winch line pull1200 kgm
Hydraulic System
Main Pumps150 lt/min
Secondary Pumps60 lt/min
Working Pressure280 bar
Kelly Bar OptionsØ 355 mm
Kelly Bar Elements Lenght Depth Option 1 7 3200 mm 21,5 m Option 2 7 2700 mm 18 m Option 3 7 2500 mm 16,5 m Option 4 7 2000 mm 13 m Option 5 7 1600 mm 10 m Other kelly bars available on request
Base Machine
TypeEurocomach ESP100
EngineYanmar 4TNV98
Engine Power73HP - 53,7kW
Fuel Tank105 l
Hydraulic Tank90 l
Drilling Performance
Diameter800 mm
Max Depth18 m
Crowd System
Pull Down Force8000 kgm
Extraction Force15000 kgm
Rotary Stroke1000 mm
Rotary Head
Nominal Torque3500 kgm
Drilling Speed24 RPM
Spin off Speed60 RPM
Transport
Width1980 mm
Lenght3985 mm
Height2720 mm
Weight approx13000 kg
Mast
Inclination Angle dx/sx3 deg
Mast Vertical Stroke1200 mm
Winches
Main Winch line pull4500 kgm
Aux Winch line pull1000 kgm
Hydraulic System
Main Pumps185 lt/min
Secondary Pumps20 lt/min
Working Pressure240 bar
Kelly Bar OptionsØ 355 mm
Kelly Bar Elements Lenght Depth Option 1 7 3200 mm 21,5 m Option 2 7 2700 mm 18 m Option 3 7 2500 mm 16,5 m Option 4 7 2000 mm 13 m Option 5 7 1600 mm 10 m Other kelly bars available on request
Base Machine
TypeEurocomach ESP100
EngineYanmar 4TNV98
Engine Power73HP - 53,7kW
Fuel Tank105 l
Hydraulic Tank90 l
Drilling Performance
Diameter1000 mm
Max Depth24 m
Crowd System
Pull Down Force8000 kgm
Extraction Force15000 kgm
Rotary Stroke1000 mm
Rotary Head
Nominal Torque4800 kgm
Drilling Speed20 RPM
Spin off Speed60 RPM
Transport
Width2320 mm
Lenght7341 mm
Height2686 mm
Weight approx12500 kg
Mast
Forward Inclination22 deg
Backward Inclination22 deg
Lateral Inclination5 deg
Mast Vertical Stroke1200 mm
Winches
Main Winch line pull5000 kg
Aux Winch line pull1500 kg
Hydraulic System
Main Pumps185 l
Secondary Pumps20 l
Working Pressure290 bar
Kelly Bar OptionsØ 355 mm
Kelly Bar Elements Lenght Depth Option 1 7 2600 mm 16 m Option 2 7 3800 mm 24 m Other kelly bars available on request
Base Machine
TypeEurocomach ESP100
EngineYanmar 4TNV98
Engine Power73HP - 53,7kW
Fuel Tank105 l
Hydraulic Tank90 l
Drilling Performance
Diameter1000 mm
Max Depth24 m
Crowd System
Pull Down Force8000 kgm
Extraction Force15000 kgm
Rotary Stroke2000 mm
Rotary Head
Nominal Torque4800 kgm
Drilling Speed20 RPM
Spin off Speed60 RPM
Transport
Width2320 mm
Lenght6800 mm
Height2870 mm
Weight approx14000 kg
Mast
Inclination Angle3 deg
Winches
Main Winch line pull5000 kgm
Aux Winch line pull1500 kgm
Hydraulic System
Main Pumps185 l
Secondary Pumps20 l
Working Pressure290 bar
Kelly Bar OptionsØ 355 mm
Kelly Bar Elements Lenght Depth Option 1 4 5000 mm 20 m Option 2 5 5000 mm 24 m Other kelly bars available on request
Base Machine
TypeDOOSAN
EngineDL06K
Engine Power110HP - 82 kW
Fuel Tank265 l
Hydraulic Tank150 l
Drilling Performance
Diameter1200 mm
Max Depth28 m
Crowd System
Pull Down Force10000 kgm
Extraction Force18000 kgm
Rotary Stroke2500 mm
Rotary Head
Nominal Torque6000 kgm
Drilling Speed20 RPM
Spin off Speed60 RPM
Transport
Width2500 mm
Lenght10348 mm
Height3385 mm
Weight approx18000 kg
Mast
Inclination Angle3 deg
Winches
Main Winch line pull8000 kg
Aux Winch line pull2500 kg
Hydraulic System
Main Pumps2 x 114 l
Secondary Pumps1 x 33 l
Working Pressure300 bar
Kelly Bar OptionsØ 355 mm
Kelly Bar Elements Lenght Depth Option 1 5 5000 mm 24 m Option 2 6 5000 mm 28 m Option 3 5 6000 mm 28 m Other kelly bars available on request
Base Machine
TypeEurocomach ESP100
EngineYanmar 4TNV98
Engine Power73HP - 53,7kW
Fuel Tank105 l
Hydraulic Tank90 l
Drilling Performance
Diameter600 mm
Max Depth11700 mm
Rotary Head
Nominal Torque4800 kgm
Drilling Speed20 RPM
Spin off Speed60 RPM
Rotary Stroke9000 mm
Transport
Width2320 mm
Lenght6800 mm
Height2870 mm
Weight14000 kg
Winches
Main Winch line pull5000 kg
Aux Winch line pull1500 kg
Extraction Force240 bar
Hydraulic System
Main Pumps185 l
Secondary Pumps20 l
Working Pressure240 bar
Winch Pull Down - optional
Pull Down Force1500 kgm
Base Machine
TypeDOOSAN
EngineDL06K
Engine Power110HP - 82kW
Fuel Tank265 l
Hydraulic Tank150 l
Drilling Performance
Diameter600 mm
Max Depth12000 mm
Rotary Head
Nominal Torque6000 kgm
Drilling Speed20 RPM
Spin off Speed60 RPM
Rotary Stroke9000 mm
Transport
Width2500 mm
Lenght10348 mm
Height3385 mm
Weight18000 kg
Winches
Main Winch line pull8000 kg
Aux Winch line pull2500 kg
Extraction Force32000 kgm
Hydraulic System
Main Pumps2 x 114 l
Secondary Pumps1 x 33 l
Working Pressure300 bar
Winch Pull Down - optional
Pull Down Force1500 kgm
BT2.5 Telescopic
BT3.5 Full Radio
BT3.5 Telescopic
BT4.5 Boom
BT4.5 LDP
BT6.0 LDP
BT4.5 CFA
BT6.0 CFA
BT 4.5 LDP
DEC BT 4.5 is great option for piles of 1000mm diameter and 24m depth. It can be equipped with extendable crawlers to add more stability and with modular mast. The BT 4.5 is mounted on Eurocomach ESP100, the only 10 ton excavator available on the market with extendable crawlers.
